قیمت این محصول
تماس بگیرید
تمامی محصولات ارائهشده توسط بلبرینگ اسکوئی با ضمانت اصالت کالا و کیفیت تضمینشده عرضه میشوند.
| Rating Load (kg) | Static permissible moment of load | Weight | |||||
|---|---|---|---|---|---|---|---|
| C | Co | Mx(kgf-mm) | My(kgf-mm) | Mz(kgf-mm) | Block (kg) | Rail (kg/m) | |
| TRI115FN | 1206 | 2206 | Single Block | Single Block | Double Block | 0.17 | 1.32 |
| TRI115FL | 1343 | 2574 | 16,436 | 14,884 | 70,960 | 0.26 | |
| TRI115FE | 1560 | 3187 | 23,740 | 31,616 | 145,220 | 0.26 | |
| TRI120FN | 2050 | 3696 | 37,334 | 33,268 | 157,298 | 0.36 | 2.28 |
| TRI120FL | 2125 | 3891 | 39,299 | 36,965 | 176,924 | 0.4 | |
| TRI120FE | 2553 | 5058 | 51,089 | 63,229 | 284,163 | 0.53 | |
| TRI125FN | 2581 | 4503 | 52,239 | 43,407 | 207,324 | 0.54 | 3.17 |
| TRI125FL | 2875 | 5254 | 60,945 | 59,579 | 277,678 | 0.62 | |
| TRI125FE | 3248 | 6255 | 72,554 | 85,112 | 391,311 | 0.78 | |
| TRI130FN | 3807 | 6483 | 90,722 | 74,970 | 355,321 | 1.31 | 4.54 |
| TRI130FL | 4098 | 7203 | 100,803 | 93,100 | 438,966 | 1.42 | |
| TRI130FE | 4791 | 9004 | 126,003 | 147,000 | 677,068 | 1.77 | |
| TRI135FN | 5090 | 8346 | 142,722 | 106,070 | 519,799 | 1.36 | 6.27 |
| TRI135FL | 5502 | 9328 | 159,512 | 133,367 | 656,509 | 1.58 | |
| TRI135FE | 6667 | 12274 | 209,885 | 233,977 | 1,070,533 | 2.11 | |
| TRI145FL | 7572 | 12808 | 292,657 | 220,751 | 1,030,183 | 2.66 | 10.4 |
| TRI145FE | 8852 | 16010 | 365,821 | 348,554 | 1,598,703 | 3.55 | |
| TRI155FL | 14703 | 21613 | 571,342 | 411,729 | 2,019,184 | 3.62 | 16.1 |
| TRI155FE | 17349 | 27377 | 723,699 | 670,530 | 3,148,637 | 4.71 | |
| TRI165FL | 22526 | 31486 | 973,074 | 695,840 | 3,594,277 | 7.96 | 22.54 |
| TRI165FE | 27895 | 42731 | 1,320,601 | 1,307,568 | 6,312,759 | 11.35 | |
